Hydraulic cylinder
Sensor Thin Hydraulic Cylinder
LA TYPE
Sensor hydraulic thin cylinder attaches with sensor pistons. This, together with magnetic spring access switch, can offer signal inspection functions.
Feature: taking little space
Use of pressure: 140 kg/cm2(14MPa)
1.Sensor Thin Hydraulic Cylinder, Body: SUS 304 Stainless Steel
2.Type：LA
3.Bore Size (mm)
4.Stroke (mm)
5.Rod Type: N: Tapping, W: Thread, T: Lathe slot, T2: Mill slot
6.Sensor cord x 2
Pressure 140 kg/cm2
Max. Pressure 210 kg/cm2
Min. Working Pressure 5 kg/cm2
Working Speed 8-100mm/sec
Working Temperature -10~+60°C
Body SUS 304 Stainless Steel
Specification
