CNC Milling Machine
CNC Milling Machine-EMB Series
EMB-750-1050
Product Description
FEATURES:
1. Hi-rigidity machine structure designs and the main casting is made of meehanite cast iron which is annealed perfectly to eliminate internal residual stress.
2. Y, Z axis square rigid ways and dovetail slideway for saddle (X axis), furthermore, the all slideway be treated heat-treatment & precisely ground & scrapped etc.
3. Rugged stand & boxed structure column and integral heavy duty bed type designs and coupled reinforced ribs, advance machining servicing life & accuracy.
4. The spindle is made of SCM-21 steel and tempered stress relieved, carburized & precisely ground etc., and then, equipped with P4 level bearings, hi-precision.
Specification
| ■ Standard Accessories | ■ Optional Accessories | ||
| 1 | Tool release device | 1 | Spindle speed 10000 / 12000 rpm |
| 2 | Automatic lubricator | 2 | Spindel cooling system |
| 3 | Cooling system | 3 | 4th axis rotary table |
| 4 | Air blast | 4 | Arm type magazine 20 / 24 tools |
| 5 | Heat exchange for control box | 5 | Armless type magazine 16 / 20 / 24 tools |
| 6 | Semi enclosed splash guard | 6 | Oil skimmer |
| 7 | Halogen work light | 7 | CE / CSA approval specification |
| 8 | Remote MPG | 8 | Outside power transformer |
| 9 | RS-232 interface | ||
| 10 | Alarm lamp | ||
| 11 | Rigid tapping | ||
| 12 | Automatic power off | ||
| 13 | Leveling bolts and blocks | ||
| 14 | Tools & Tool box | ||
