♦ User Identification: RFID
♦ Easy To Use: LED Indicator, Abnormal detection, Automatic power off
♦ Cloud Service: Connect to Fortune back office management system (Back office management system required)
♦ Billing Service: Check on charging record, Billing data setting (Back office management system required)
♦ App Application: Operation by mobile phone (Back office management system required)
♦ Customized Exterior: Customized exterior available
1. Input:
(1) Voltage Range: AC 220V
(2) Frequency Range: Single phase 60Hz
(3) Input Current: 80A
(4) Input Power Connection: Line1, Line2, and ground
2. Output:
(1) Voltage Range: AC 220V
(2) Frequency Range: 60Hz
(3) Output Current: 80A
(4) Output Power: 18.4kW (maximum)
Physical Specifications
1. Cable Type: SAE J1772
2. Cable Length: 17FT (5.1M)
3. Enclosure Dimensions: H1260※W270※D135 (mm)
4. Weight: 4.8 (KG) Without Fix Stand
User Interface
1. Button: Emergency button
2. Indicator Light:
(1) Standby: Green
(2) Charging: Yellow
(3) Fault: Red
3. User Identified: RFID (Mifare Card)
Protection
1. Protection: Over-current protection、Short-circuit protection、Grounding protection
Environmental
1. Operating Temperature: -10°C to +50°C
2. IP: IP 55
3. Humidity <95%
Standards Compliance
1. Standards: SAE 1772
Main Export Market
Asia ,Central America ,Europe ,Middle East ,North America ,Oceania ,Other ,South America
Product Certification:
