Vertical Turret Milling Machine
Vertical Turret Milling Machine
YSM-16 SERIES
X/Y/Z travel : 850/426/400 mm
Spindle taper : R8/NT30/NT40(Ø85)
Spindle motor : 3HP
Hardened ground-X/Y
Square way-Y
Specification
- The main casting part is made of meehanite casting.
- The spindle is one piece machined from SCM440 alloysteel, thermal refining, high-frequency and precision polishing.
- Milling head type:
-Variable (V) Steps (S) Inverter (C)
| 8 Steps | ||
| 60HZ | 80-135-210-325-600-1115-1750-2700(RPM) | |
| 50HZ | 54-100-170-280-510-835-1430-2260(RPM) | |
| 16 Steps | ||
| 50HZ | 2P | 136-230-370-570-1080-1820-3000-4560(RPM) |
| 4P | 68-115-185-285-400-910-1500-2280(RPM) | |
-Inverter type used YASKAWA VFD.
- Maximum spindle speed up to 4560rpm/50HZ
- Used type B belt drive.
- Hardened and ground X,Y axes slideway ; Turcite-B coated on X Y ways.
- Unique Y axis anti-slip fixing lock.
- Square way design on Y.
