Power Chucks for CNC Lathes

3-jaw wedge type through-hole power chuck (with adaptor)(big hole)

TF-3CA/3XA

Specification

Dim\Model	TF3C-6A5	TF3C-8A6	TF3X-10A8	TF3X-12A8	TF3X-12A11
Through-Hole (mm)	52	66	75	100	100
Plunger Stroke (mm)	12	17	19	23	23
Jaw Stroke (Dia)(mm)	5.5	7.4	8.8	10.6	10.6
Max. Draw Bar Pull Force (kgf)	2200	3400	4300	5500	5500
Max. Gripping Force (kgf) / (kgf/cm²)	5700 / 18	8700 / 18	11000 / 27.5	14300 / 19.5	14300 / 19.5
Max. Speed (r.p.m.)	6000	4600	4200	3300	3300
Weight (kg)	14.2	24.5	37.4	61	61
Matching Cylinder	RCS-8	RCS-10	RCS-10X	RC-15	RC-15
Matching Soft Jaw	HC06	HC08	HC10	HC12	HC12
Matching Hard Jaw	HJ06	HJ08	HJ10	HJ12	HJ12

Dimensions

Dim\Series	TF3C-6A5	TF3C-8A6	TF3X-10A8	TF3X-12A8	TF3X-12A11
A	175	215	254	318	318
B	75	108.5	113	137	126
D	20	25	30	30	30
E	30	22.5	18	33	22
F	82.563	106.36	139.719	139.719	196.8
C (H6)	140	170	220	300	300
H	104.78	133.4	171.45	171.45	235
J	16	16	20	20	20
K	6xM10	6xM12	6xM16	6xM20	6xM20
L	52	66	78	110	110
M	5	7	5	6	6
N (Max)	32	46	51	68	68
N (Min)	29.25	42	46.6	63	63
O (Max)	24	25.5	34.5	53.5	53.5
O (Min)	7.5	10.5	12	19	19
P (Max)	25	31.5	26.5	37	26
P (Min)	12.5	14.5	7.5	14	3
R	12	14	16	21	21
S	19	25	25	28	28
T	32	37	42	52	52
U (Max)	M60x2.0	M74xP2.0	M87x2.0	M115x2.0	M115x2.0
V	-	-	-	6xM16	-
W	66	82	96	127	127
X	16	16	16	20	20
Y	36	45	60	60	60
A1	65	80	102	140	140
M1	M8	M8	M10	M10	M10
t	5	5	5	5	5
Reference	Fig1	Fig1	Fig1	Fig2	Fig1
