Specification
Specification
| Dim\Model | VT-206 | VT-208 | VT-210 | VT-212 | VT-215 |
|---|---|---|---|---|---|
| Jaw Stroke (Dia)(mm) | 8.5 | 8.8 | 8.8 | 10.5 | 16 |
| Plunger Stroke (mm) | 20 | 21 | 25 | 30 | 35 |
| Max. Gripping range (mm) | 165 | 210 | 254 | 304 | 381 |
| Min. Gripping range (mm) | 18 | 22 | 24 | 25 | 68 |
| Max. Pull Force KN (kgf) | 12 (1224) | 16.5 (1683) | 19.5 (1988) | 27.5 (2804) | 55 (5609) |
| Max. Gripping Force KN (kgf) | 34 (3469) | 50 (5099) | 72 (7242) | 104 (10505) | 166 (16827) |
| Max. Speed (r.p.m.) | 5100 | 4650 | 3810 | 3200 | 2800 |
| Weight (kg) | 12 | 22 | 33 | 57.3 | 96 |
| Moment of Inertia (kg.m²) | 0.04 | 0.13 | 0.29 | 0.7 | 1.7 |
| Matching Cylinder | MH100 | MH125 | MH125 | MH150 | MH200 |
| Matching Soft Jaw | HC06 | HC08 | HC10 | HC12-1 | HC15-1 |
| Matching Hard Jaw | HJ06 | HJ08 | HJ10 | HJ12-1 | HJ15-1 |
Dimensions
| Dim\Model | VT-206 | VT-208 | VT-210 | VT-212 | VT-215 |
|---|---|---|---|---|---|
| A | 165 | 210 | 254 | 304 | 381 |
| B | 74 | 85 | 89 | 106 | 114 |
| C | 104.78 | 133.35 | 171.45 | 171.45 | 235 |
| E (Max) | 18 | 22.5 | 37.5 | 47 | 50.25 |
| E (Min) | 7.5 | 9 | 10.5 | 11 | 23.25 |
| F | 20 | 25 | 30 | 30 | 43 |
| G | 4 | 5 | 5 | 5 | 2 |
| H (Max) | 106.5 | 132 | 163 | 168 | 104 |
| H (Min) | 86.5 | 111 | 138 | 138 | 69 |
| I | 36 | 36 | 36 | 36 | 55 |
| J | M16x2.0 | M20x2.5 | M20x2.5 | M20x2.5 | M30x3.5 |
| K (H6) | 140 | 170 | 220 | 220 | 300 |
| L | 6-M10 | 6-M12 | 6-M16 | 6-M16 | 6-M20 |
| M | 5 | 5 | 5 | 6 | 6 |
| N | 14 | 20 | 18 | 22 | 29 |
| O | 34 | 38 | 45 | 50 | 60 |
| P | 21 | 25 | 34 | 34 | - |
| Q (Max) | 37.8 | 46.3 | 51.1 | 61 | 77.5 |
| Q (Min) | 33.5 | 41.9 | 46.7 | 55.75 | 69.5 |
| R | 31 | 35 | 40 | 50 | 50 |
| S | 12 | 14 | 16 | 18 | 25.5 |
