Economy type of deep-hole drilling machine.
This machine is suitable for center-hole drillng, like eject hole, automobile parts, medical parts, ect.
With high-quality ball screw and servo motor for feed-axis, moving and drilling is stable and precision.
With three-jaw manual chucks, clamping part is flexible. Hydraulic chuck is available.
As processing, spindle is rotating and component is stationary.
With outer-controller and MPG, operator uses the machine very convenient.
Automatic lubrication pump is provided as standard accessory to ensure all bearing surface and screws are well lubricated.
CE requirement is available
Capacity
- Number of drill spindle: 2 Nos
- Range of drilling dia.: 3 ~ 25mm ( 5 ~ 25mm )
- Max. depth of drilling: 500 / 1,000mm
Speed
- Drill feed range: 10 ~ 500 mm/min
- Spindle speed range: 0 ~ 6,000 rpm
Hydraulic system
- Coolant pump pressure range:10 ~ 100 kg/cm²
- Pump output range: 30 ~ 60 L/min
- Coolant tank capacity: 1200 L
Working table stroke
- Effective drill stroke (Z-Axis): 500mm / 1,000mm
Drive motor
- Spindle motor:5HP x 2 ( 10 HP x 2 )
- Z-Axis: 2 HP
- Chip screw: 1/8 HP
- Coolant pump:5HP x 2 ( 10 HP x 2 )
- Automatic lubrication: 51W
- Total machine power:35HP / 50 HP
- Net weight: 3,000 / 3,500kgs
- Floor space (Approx): 3,300 x 3,500 x 1,700 / 3,800 x 3,500 x 1,700 mm
Standard accessories
- Paper filter
- Magnetic separator
- Chip and oil separator system
- High pressure oil pump
- Auto lubrication system
- Protecting drill torsion system
- Outer oil tank/Oil level gauge
- Tranformer
- Leveling screws & block
- Tool box / work light / alarm light
- Mechanical / Electrical operation manual
Special accessories
- Oil cooler
- Coolant oil
- Gundrill
- Guide bush
- Rubber bush
- Automatic Voltage stabilizer
- Fully enclosed guard
- Gundrill grinder
- Safety door interlock
- Oil mist collector
- Filtration housing
- Centrifuge
