CNC Surface Grinders

CNC Surface Grinders Inquery64CNC

PSG-64CNC

Specification

Model Description	PSG-64CNC
General Capacity
Table size	600x400mm
Max.grinding length	650mm
Max.grinding width.	420mm
Distance from table surface to spindle center	500mm
Longitudinal Movement
Table speed(approx)	25 M/min
CrossFeed Movement
Continuous feed(approx)	60HZ 1000mm/min
Handfeed 1.gra.	0.001/0.01/0.02mm
Least input increment	0.001mm
Vertical Downfeed
Handfeed 1.gra.	0.001/0.01/0.02mm
Rapid feed	1000 mm/min
Least input increment	0.001mm
Grinding Wheel
Wheel size(diaxwidthxbore)	355x38x127 mm
Wheel speed	50HZ 1500 r.p.m
Wheel speed	60HZ 1800 r.p.m
Motors
Spindle Motor	5HP
Cross feed Motor	AC 0.75 KW
Hydraulic Motor	2HP
Elevation Motor	AC 1KW
Weight
Net/Packing gross	3000kgs
Packing size
Length x width x heigh	2700x2797x2170mm

Standard Accessories

Grinding Wheel with flange

Wheel Balancing arbor

Wheel dresser with diamond

Tooling box and tools

Flange extractor

Wheel Balancing base

Leveling screw and plates

Working lamp

Electro Magnetic Chuck

Coolant System

Auto paper strip filter and magnetic separator with coolant system

Paper Filter with coolant system

Fully enclosed splash guard

Auto Demagnetizer for magnetic chuck

Dust & coolant unit

Magnetic separator with coolant system

Hydraulic Oil Cooler
