Specification
| Model | S-460HB | |
|---|---|---|
| Capacity | ● | 420 mm (16.5") |
| ■ | 420 x 420 mm (16.5"W x 16.5"H) | |
| Bundle Cutting | Width | 195 to 300 mm (8" to 12") |
| Height | 90 to 200 mm (3.5" to 8") | |
| Blade Speed | 20 to 100 m/min (65 to 330 fpm) (INVERTER) | |
| Motor | Blade Drive | 5.5 kW (7.5HP) |
| Hyd. Pump | 1.5 kW (2HP) | |
| Coolant Pump | 0.2 kW (1/4HP) | |
| Blade Size | 4570 x 41 x 1.3 mm (180" x 1.6" x 0.05") | |
| Blade Tension | Hydraulic | |
| Index Length | 500 mm (20") 500 mm x 9 times (20" x 9) | |
| Machine Weight | 2360 kg (5190 lb) | |
| Floor Space (L x W) | 2590 x 2180 mm (102" x 85.8") | |
* All specifications, dimensions and design characteristics shown in this catalogue are subject to change without prior notice.
